Stock Code:
MP-60-18V
Stock Level:
In Stock
UTILITOOL MANDREL PULLING MACHINE W. RA HEAD & MAKITA BATT.
POA
Description
UtiliTool hydraulic track insert installation tool with interchangeable right-angle and straight pulling heads, for installing and removing track inserts across light rail, heavy rail, crane rail and girder rail. Runs on 18V Makita batteries already on site, so there's no proprietary battery platform to buy into. Custom applications available.
Key features
- Quick-connect interchangeable heads swap between right-angle and straight pulling heads without tools.
- Remote head on a 900mm highly flexible hose, for use in tight environments like track points and turnouts.
- TouchSmart LCD display shows system pressure at a glance.
- Built-in over-pressure relief valve with automatic safe release.
- Mechanical safety retraction if battery power is lost.
- Compatible with 18V Makita Li-ion batteries, no proprietary battery or charger required.
- Optional TIRK-U removal adaptor converts the tool for insert removal, covering the full insert lifecycle with one tool.
- Lightweight, compact 4 kg pistol-grip unit for one-operator, one-handed use.
Specifications
| Model | MP-60-18V |
|---|---|
| Max. force | 54kN |
| System pressure | 60MPa |
| Power supply | 18V 5.0Ah Li-ion battery |
| Motor | DC18V brushless motor |
| Dimensions | 1075mm × 90mm × 320mm |
| Weight | 4kg |
Right pulling head included, straight sold separately. TIRK-U insert removal adaptor is an optional accessory.
Details
-
Size:1075MM × 90MM × 320MM
-
Colour:GREY / BLACK
